Description
A flatbed truck is a truck with a rigid design. The advantage of a flatbed truck is that it is easy to load and unload goods because they have an open bed and can be quickly loaded and unloaded using tools such as cranes and forklifts. Flatbed trucks are mainly used to transport heavy, oversized, wide, and unbreakable goods such as machinery, construction materials, Farming materials, and heavy equipment.
Why choose this Howo 20-ton flatbed truck with a crane?
1. The flatbed is 6.5m long, with a loading capacity of 20 tons, made of 8mm thickness pattern steel.
2. It is equipped with mechanical rear ramps in the rear(optional hydraulic ramps)
3. Weichai engine, with a maximum engine power of 380 horsepower.
4. XCMG brand crane, telescopic boom, or knuckle boom (crane lifting capacity can choose 8-ton, 10-ton, 12-ton, 14-ton)
5. It is equipped with a 10-ton hydraulic winch.(optional according to customer’s requirement)
| Vehicle Description | |
| Overall dimensions | 11950*2500*3200mm |
| GVW | 31000kg |
| Curb weight | 7525kg |
| Chassis brand | Sinotruk Howo |
| Traction type | 6X4 |
| Flatbed Description | |
| Loading capacity | 15-20T |
| Length | 6800mm |
| Material | Checkered plate |
| Thickness | 8mm |
| Standard configuration | Equipped with double spring ladder; Equipped with rear landing leg. |
| Optional configuration | Single cylinder hydraulic ladder; Double cylinder folding ladder; Intermediate extension. |
| Chassis Description | ||
| Chassis model | ZZ1257M4647C | |
| Cab | Flat-roof, half row | |
| Wheelbase | 4600+1350mm | |
| Tire specification | 295/80R22.5 | |
| Tire quantity | 10+1 units | |
| Engine | Engine model | WP10.380E22 |
| Emission level | Euro 2 | |
| Displacement/output | 9726ml/279kw | |
| Horsepower | 380hp | |
| Gearbox | Type | Manual |
| Number of gears | 10 forward gears & 2 reverse | |
| Brake system | Full air brake system | |
| Axle | Front | 7.5T |
| Rear | 16T | |
| Suspension | Front | Leaf springs, with shock absorber |
| Rear | Leaf springs | |
| Fuel tanker | Type | Steel tanker, with lockable cap |
| Capacity | 400L | |
Tags: flatbed truck, self loader, Excavator transport truck
