ISUZU 4×2 15cbm Compactor Garbage Truck

The ISUZU 15cbm garbage compactor truck is equipped with an ISUZU engine, with a maximum engine power of 205 horsepower.

The garbage compactor body is made of high-tensile carbon steel, and equipped with a sewage tank to collect wastewater.

Dual operation modes, manual and automatic operation.

Various types of container lifting systems can chosen.

Description

The Isuzu compactor garbage truck has become an effective solution for urban garbage disposal with its high efficiency, environmental protection, safety, and economy, as well as the design of automated operation and double insurance system. ‌

Brief introduction of this ISUZU 4X2 15cbm garbage compactor truck:

  • The garbage compactor truck adopted ISUZU GIGA’s high-end chassis, with high quality and high performance.
  • The garbage compactor truck is equipped with a 4HK1-TCG61 engine, with a maximum engine power of 205 horsepower.
  • The garbage compactor truck is equipped with an ISUZU MLD gearbox.
  • The garbage compactor body’s main parts all adopt well-known brands, which can ensure the garbage compactor with good performance and lifetime.
  • The garbage compactor body has a dual sewage tank to collect the wastewater generated when working, which avoids secondary pollution.
  • Manual and automatic dual operation mode.



Why choose this ISUZU 4×2 15cbm Compactor Garbage truck?

  • High efficiency and environmental protection: Isuzu compactor garbage trucks use advanced compression technology, which can efficiently compress garbage, reduce the volume of garbage, and increase the loading capacity of garbage, thereby reducing the number of transportation and reducing transportation costs. ‌At the same time, the vehicle also has an automatic control system and safety protection devices to ensure safe and reliable operation, improve the efficiency of garbage disposal, and reduce the impact on the environment



  • ‌Economy: Isuzu compactor garbage trucks have a good economy. When special equipment is working, the computer control system automatically controls the throttle, which is more fuel-efficient. ‌In addition, the chassis configuration of the vehicle is economical and affordable, the Qingling Isuzu chassis has strong maneuverability, and the Isuzu engine is fuel-efficient and cost-effective.



  • ‌Automated operation‌:‌ The Isuzu compactor garbage truck adopts a computer control system, and the driver is required to operate all filling and unloading operations. It can be set to fully automatic and semi-automatic operation modes to realize operation automation.



  • ‌Double insurance system‌:‌ The operation system has the dual functions of computer control and manual operation, which guarantees and improves the utilization rate of the vehicle and provides double insurance.



  • ‌Simple garbage collection method‌:‌ It changes the dirty and messy old appearance of garbage bins placed all over the streets of the city, eliminates secondary pollution, and makes garbage collection easier.



  • High compression ratio and loading capacity‌:‌ The maximum crushing pressure reaches 12 tons, and the loading capacity is equivalent to two and a half times that of non-compressed garbage of the same tonnage, providing greater loading capacity.



SPECIFICATION
Product name ISUZU 4X2 15 cbm compactor garbage truck
Overall dimension (L x W x H) 9260×2400×3380 mm
GVW(Kg) 18000 (Kg)
Curb weight 7200 (Kg)
Rated load weight 10930 (Kg)
Chassis Specification
Cabin Single row, 3 seats,  air conditioner
Drive Type 4×2
Wheelbase 4500 mm
Engine Model 4HK1-TCG61
Maximum horsepower 205 hp
Displacement 5193 cc
Type Diesel, 4 cylinders in-line, inter-cooled turbocharged
Gearbox Manual, 6 forwards, and 1 reverse
Tires 295/80R22.5, 6+1 pieces
Upper body specification
Body capacity 15 cubic meters
Materials 5mm Q345 high-tensile steel
Fill hopper capacity 1.2 cbm
Sewage tank 200 liters
Filling work cycle time 20~25 s
Discharge model Horizontal Ejection
Control system Electrically hydraulic control

Manual hydraulic control

Control panel English or your language
All standard accessories: Dust bin lifter, ladder, warning lights, emergency stop button, handrail, fire extinguisher, basic tool kit, English manual….
Optional ** Back alarm and Camera can be equipped.

** Italy multi-valve can be chosen.

**240L (single bin or double bin) or standard 660L, 1100l bins with bin lifter can be choose.
