Description
Shacman garbage compactor truck can meet all your needs for garbage disposal, garbage compression, and transportation. The chassis is equipped with a Weichai 380-horsepower diesel engine with strong power and a Fast 9-speed gearbox. The upper body of the compression garbage truck is made of a high-strength Q345 manganese steel plate. Using the intelligent control system, centralized control can be achieved in the cab. With automatic and manual dual control modes, it can control the garbage truck’s operation in the cab, the middle, and the rear of the vehicle, which is convenient and efficient.
Why choose this Shacman 23cbm garbage compactor truck?
1. This garbage adopts a Shacman H3000 chassis, with a maximum engine power of 380 horsepower.
2. The main components adopt China’s well-known brands which can ensure the garbage truck has good performance.
3. A dual wastewater collection tank is used to collect sewage generated during the garbage compression process
4. Simens PLC electronic control operating system
5. We are a garbage compactor truck manufacturer, you can get a bottom price from us.
| SPECIFICATION | ||
| Product name | Shacman 23cbm garbage compactor truck | |
| Overall dimension (L x W x H) | 10490×2550×3780 mm | |
| GVW(Kg) | 25000 (Kg) | |
| Curb weight | 10600 (Kg) | |
| Rated load weight | 13830 (Kg) | |
| Chassis Specification | ||
| Cabin | Single row, has sleeper bed, 3 seats, air conditioner | |
| Drive Type | 6×4 | |
| Wheelbase | 4375+1400 mm | |
| Engine | Model | WP10.380E22 |
| Maximum horsepower | 380 hp | |
| Displacement | 9726 cc | |
| Type | Diesel, 6 cylinders in-line, inter-cooled turbocharged | |
| Gearbox | Manual, 9 forwards, and 1 reverse | |
| Tires | 12.00R20, 10+1 pieces | |
| Upper body specification | ||
| Body capacity | 23 cubic meters | |
| Materials | 4mm Q345 high-tensile steel | |
| Fill hopper capacity | 1.2 cbm | |
| Sewage tank | 200 liters | |
| Filling work cycle time | 20~25 s | |
| Discharge model | Horizontal Ejection | |
| Control system | Electrically hydraulic control
Manual hydraulic control |
|
| Control panel | English or your language | |
| All standard accessories: Dust bin lifter, ladder, warning lights, emergency stop button, handrail, fire extinguisher, basic tool kit, English manual…. | ||
| Optional | ** Back alarm and Camera can be equipped.
** Italy multi-valve can be chosen. **240L (single bin or double bin) or standard 660L, 1100l bins with bin lifter can be choose. |
|
